This industrial panel pc features a built-in high-definition front camera, enabling real-time image capture and video monitoring. Ideal for applications such as facial recognition, equipment status logging, and remote assistance, it combines robust industrial design with powerful performance—making it a smart solution for industrial automation, intelligent security, and smart retail environments.
Introduction
- Intel® Core™ i7/i5/i3 processors, compatible from Celeron® to 12th Gen Intel® Core™
- 15.6-inch 16:9 TFT LCD, 1920 × 1080 (SXGA).
- 10-point capacitive touch, IP65 front, 6H hardness.
- Dual Intel® I210 Gigabit Ethernet.
- I/O: USB 2.0 ×2, USB 3.0 ×4, Audio ×1, Mic ×1, RS-232 ×3, HDMI, VGA.
- 9–36V DC wide-range power input.
- Expansion: dual M.2 2280 NVMe, M.2 2230 Wi-Fi.
- TPM 2.0 hardware security support.
- CESIPC BlockCore modular design.
- CESIPC SafeCore™ power-loss protection.
- Auto power-on after power recovery.
- Industrial-grade 6061 aluminum alloy enclosure.
★ Front Panel with Camera
► System Core
| CPU | Celeron J1900 | Celeron J6412 | I3-10110U | I5-10210U | I7-10510U | i3-1215U | i5-1235U | i7-1250U |
| Cores | 4 | 4 | 2 | 4 | 4 | 2-6 | 2-10 | 2-10 |
| Threads | 4 | 4 | 4 | 8 | 8 | 4-8 | 4-12 | 4-12 |
| Frequency | 2.0-2.4 | 2.0-2.8 | 2.1-4.1 | 1.9-4.2 | 1.8-4.9 | 1.2-4.4 | 1.3-4.4 | 1.0-4.7 |
| Cache | 2MB | 4MB | 4MB | 6MB | 8MB | 10MB | 12MB | 12MB |
| TDP | 10W | 10W | 15W | 15W | 15W | 15W | 15W | 15W |
| Graphics | HD | UHD 600 | UHD | UHD 620 | UHD 620 | UHD 730 | Iris Xe | Iris Xe |
| Memory | 4-8GB DDR3L | 4-8GB DDR4 | 4-32GB DDR4 | 4-32GB DDR5 | ||||
| Storage | 1 x mSATA | 1 x mSATA SSD + 1 x M.2 SSD | ||||||
► Camera
| Model | Resolution | Frame Rate | Lens Type | Viewing Angle | Special Features | Interface |
|---|---|---|---|---|---|---|
| Cam-AF1080 | 2MP (1920×1080) | 30 fps @ 1080p | Auto Focus | 70° | Plug & play, low-light support | USB 2.0 |
| Cam-FF720 | 1MP (1280×720) | 30 fps @ 720p | Fixed Focus | 60° | Compact size, basic monitoring | USB 2.0 |
| Cam-AF4K | 8MP (3840×2160) | 30 fps @ 4K | Auto Focus | 80° | 4K UHD, HDR support, digital zoom | USB 3.0 |
| Cam-IR720 | 1MP (1280×720) | 30 fps @ 720p | Fixed Focus | 70° | IR night vision, IR-cut filter | USB 2.0 |
| Cam-QR720 | 1MP (1280×720) | 60 fps @ 720p | Fixed Focus | 60° | Optimized for QR/barcode scanning | USB 2.0 |
| Cam-Wide1080 | 2MP (1920×1080) | 30 fps @ 1080p | Fixed Focus | 120° Ultra-wide | Wide-angle for full operator view | USB 2.0 |
► I/O Ports
| CPU | Celeron J1900 | Celeron J6412 | I3-10110U | I5-10210U | I7-10510U | i3-1215U | i5-1235U | i7-1250U |
| USB 2.0 | 5 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| USB 3.0 | 1 | 4 | 4 | 4 | 4 | 4 | 4 | 4 |
| RS232 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 |
| RS485 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| VGA | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| HDMI | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Ethernet | 2 x Intel I210 | 2 x Intel I210 | 2 x Intel I210 | 2 x Intel I210 | 2 x Intel I210 | 2 x Intel I210 | 2 x Intel I210 | 2 x Intel I210 |
| Audio | 3.5mm TRRS | 3.5mm TRRS | 3.5mm TRRS | 3.5mm TRRS | 3.5mm TRRS | 3.5mm TRRS | 3.5mm TRRS | 3.5mm TRRS |
► Camera Industrial Panel PC DC Input
| DC Input | 1 × 3-pin Pluggable Terminal Block for 12V DC9-36V DC Optional |
| Booting | AT / ATX |
►Wireless Communication
| Wi-Fi | Intel N6235 300Mbps, 802.11a/b/g/n 2.4G / 5G |
| Wireless Network | 4G LTE Full Netcom Module (optional) |
► Environmental
| Operating Temperature | 0~50℃ (-40~70℃ Optional) |
| Storage Temperature | -10~60℃ |
| Humidity | 10%~90% , Non-condensing |
► OS
| Windows | Windows 10 / Windows 11 |
| Linux | Ubuntu 12.04 / 14.04 / 16.04 / 20.04 |
► Certs & Services
| Product | CE / FCC / BISAccording to EN 55032 & EN 55035 |
| Factory | ISO9001: 2015 |
| ODM | BIOS / Boot on LOGO / OEM |
| MTBF | 60,000 Hours |
►Touch Panel
| Touch Way | Projected Capacitive Touch (Resistive Touch by Project) |
| Touch Points | 1 – 10 Touch Points |
► LCD Panel
| Size | 15.6 inch TFT Panel |
| Resolution | 1920×1080 / 16:9 |
| Brightness | 300 nits |
| Contrast | 500 : 1 |
| Protection | Front Panel IP65 |
►Project Achievements
How Camera-equipped Industrial Panel PCs Are Revolutionizing Tobacco Manufacturing
CTN‑W1592A Series — Camera‑Integrated Industrial Panel PC FAQ
15.6‑inch fanless industrial panel PC with built‑in high‑definition front camera — facial recognition, equipment status logging, remote assistance, and BlockCore™ modularity.
What makes the CTN‑W1592A different from standard industrial panel PCs?+
The CTN‑W1592A is a 15.6‑inch fanless industrial panel PC with a built‑in high‑definition front camera, designed to eliminate the need for external USB webcams or separate vision systems. Standard industrial panel PCs lack integrated imaging capability, requiring users to mount external cameras with additional cabling, mounting brackets, and power supplies — creating extra failure points and installation complexity. Key differentiators include:
• Built‑in high‑definition camera (front panel) — Supports real‑time image capture and video monitoring for facial recognition, equipment status logging, and remote assistance applications. The camera is fully sealed behind the IP65 front panel, eliminating external wiring and ingress risks [0†L3-L7].
• 5 camera models with flexible resolution and features — From 1MP/720p basic monitoring to 8MP/4K UHD auto‑focus with HDR and digital zoom. Plug‑and‑play USB interface (USB 2.0 for most models, USB 3.0 for 4K model) allows software‑selectable camera options without hardware changes [0†L24-L31].
• Intel® 12th Gen Core™ processors / Celeron options — i3‑1215U / i5‑1235U / i7‑1250U, plus 10th Gen and Celeron J1900/J6412, delivering scalable performance from lightweight HMI to edge AI inference for on‑device vision processing [0†L16-L24].
• Fanless passive cooling — Thermally engineered 6061 aluminum alloy chassis eliminates dust intake and fan‑related failures, ideal for dust‑prone industrial environments [0†L14-L15].
• BlockCore™ modular architecture — Built on CESIPC’s BlockCore™ platform, supporting i‑Door expansion modules (CAN, 5‑port LAN, isolated serial, 5G) without custom PCB development.
• SafeCore™ power‑loss protection — Prevents OS/file corruption during sudden power loss with one‑reboot recovery, critical for unattended kiosks and remote monitoring stations.
Standard commercial panel PCs lack these industrial‑grade features — particularly the integrated front camera — and would require external USB cameras, separate power supplies, and additional mounting hardware, increasing complexity and failure points [2†L10-L11].
What camera options are available — resolution, frame rate, lens type, and special features?+
The CTN‑W1592A offers five camera models to match different application requirements, all plug‑and‑play via USB interface (USB 2.0 for most models, USB 3.0 for 4K UHD model). The camera is integrated into the front panel behind the sealed IP65 cover, eliminating external wiring and ingress risks [0†L24-L31]:
Cam‑AF1080 — 2MP (1920×1080), 30 fps @ 1080p, auto focus, 70° viewing angle. Plug & play, low‑light support. Interface: USB 2.0. Best for facial recognition, operator authentication, and general‑purpose industrial vision where image quality matters.
Cam‑FF720 — 1MP (1280×720), 30 fps @ 720p, fixed focus, 60° viewing angle. Compact size, basic monitoring. Interface: USB 2.0. Economical choice for equipment status logging, basic visual inspection, and applications where only simple image capture is required.
Cam‑AF4K — 8MP (3840×2160), 30 fps @ 4K, auto focus, 80° viewing angle. 4K UHD, HDR support, digital zoom. Interface: USB 3.0 (requires USB 3.0 bandwidth). The highest‑resolution option for remote assistance, detailed defect inspection, and video surveillance where fine detail capture is essential.
Cam‑IR720 — 1MP (1280×720), 30 fps @ 720p, fixed focus, 70° viewing angle. IR night vision, IR‑cut filter (automatically switches between daytime colour and nighttime IR). Interface: USB 2.0. Designed for 24/7 security applications and dimly lit industrial environments where low‑light or no‑light operation is required.
Cam‑QR720 — 1MP (1280×720), 60 fps @ 720p, fixed focus, 60° viewing angle. Optimised for barcode / QR code scanning. Interface: USB 2.0. High‑frame‑rate (60 fps) model specifically for high‑speed scanning applications where codes move quickly past the reader — logistics sortation, parcel tracking, and warehouse automation.
All camera models are software‑selectable during ordering, and the USB interface ensures broad operating system compatibility (Windows/Linux) without proprietary drivers [2†L10-L11].
What processors and performance options are available?+
The CTN‑W1592A supports multiple CPU tiers from entry‑level Celeron to high‑performance 12th Gen Core, all sharing identical mechanical chassis, I/O layout, and mounting dimensions — simplifying spares logistics for large‑scale deployments [0†L16-L24]. Options include:
Intel Celeron® J1900 — 4 cores, 2.0–2.42GHz, 10W TDP. Memory: 4–8GB DDR3L. Entry‑level for basic HMI, equipment status logging, and lightweight camera monitoring where compute needs are minimal.
Intel Celeron® J6412 — 4 cores, 2.0–2.8GHz, 10W TDP. Memory: 4–8GB DDR4. Improved efficiency for basic facial recognition and light SCADA workloads.
10th Gen Intel® Core™ i3‑10110U / i5‑10210U / i7‑10510U — 2–4 cores, up to 4.9GHz, 15W TDP. Memory: 4–32GB DDR4. Balanced performance for real‑time facial recognition, equipment status logging with video, and remote assistance streaming.
12th Gen Intel® Core™ i3‑1215U / i5‑1235U / i7‑1250U — Up to 10 cores, up to 4.7GHz, 15W TDP. Memory: 4–32GB DDR5, Intel Iris Xe Graphics (i5/i7 models). High‑performance for edge AI inference (on‑device facial recognition, defect detection), real‑time video analytics, and multi‑camera processing.
Memory: 4–32GB DDR3L/DDR4/DDR5 depending on processor platform. Storage: 1× mSATA SSD (Celeron) or 1× mSATA SSD + 1× M.2 SSD (Core platforms) — dual‑drive architecture for OS and data separation. Operating systems: Windows 10/11, Ubuntu Linux (16.04–22.04). Celeron J1900 supports Windows 7.
For detailed specifications, download the datasheet.
What I/O ports and expansion capabilities does the CTN‑W1592A offer?+
The CTN‑W1592A provides a comprehensive industrial I/O package with the front camera as the standout feature [0†L10-L15]:
Built‑in front camera: Integrated high‑definition camera behind IP65 front panel — no external webcam or separate vision system required. Software‑selectable from 5 camera models (1MP/720p to 8MP/4K UHD) with auto focus, IR night vision, or QR‑optimised options.
USB ports: 2×USB 2.0 + 4×USB 3.0 = 6 total USB ports — connects barcode scanners, external cameras, touchscreen calibration tools, and diagnostic equipment. The 4K camera model (Cam‑AF4K) requires a USB 3.0 port for full bandwidth.
Serial ports: 3×RS232 via DB9 — interfaces with PLCs, industrial sensors, torque tools, and legacy automation equipment.
Display outputs: HDMI + VGA — dual independent displays for operator + supervisor screens or HMI + diagnostic view.
Networking: 2× Intel® I210 Gigabit Ethernet (10/100/1000M, PTP time sync support) — separated network paths for local device connectivity (IP cameras, sensors) and plant‑wide SCADA communication.
Audio: Audio ×1, Mic ×1 — public announcement integration or voice guidance for operator instructions. The built‑in microphone complements the camera for remote assistance use cases.
Internal expansion: Dual M.2 2280 NVMe slots for high‑speed storage, M.2 2230 slot for Wi‑Fi + Bluetooth, 1× Mini PCIe socket for wireless modules (4G/5G/GPIO expansion).
Modular I/O via i‑Door (BlockCore™): The i‑Door smart expansion slot accepts function modules — CAN bus, 5‑port LAN, isolated serial, 5G — snapped in without wiring or chassis modifications. Ideal for field‑configurable applications where I/O requirements vary by deployment.
What is BlockCore™ modular architecture, and how does it benefit camera‑enabled deployments?+
BlockCore™ is CESIPC’s modular computing architecture that standardises interface, structure, power, and expansion across all products. For the CTN‑W1592A, BlockCore™ delivers:
1. Integrated camera as a modular option — The front camera is factory‑integrated with software‑selectable models (AF1080, FF720, AF4K, IR720, QR720) all using the same sealed IP65 panel cutout. No external camera mounting, wiring, or separate power supply required — the camera is plug‑and‑play via USB interface and protected behind the IP65 front panel [2†L10-L11].
2. Standardised I/O expansion (i‑Door) — i‑Door expansion slots accept function modules (CAN, 5‑port LAN, isolated serial, 5G, GPIO) without custom PCB development. For deployments requiring CAN bus for robot vision integration, simply add the module — no hardware redesign [8†L8-L10].
3. Shared ecosystem across product families — The CTN‑W1592A uses the same i‑Core Board and expansion modules as other BlockCore™ industrial PCs. Standardise spares across mixed fleets of standard panel PCs, camera‑equipped units, and embedded controllers.
4. Future‑proof upgrades — Upgrade from Celeron to Core i7 by swapping only the compute board. The enclosure, integrated camera, I/O connectors, and mounting dimensions remain unchanged — no re‑certification required. For vision applications where compute requirements increase over time (e.g., adding edge AI inference), this eliminates costly hardware redesign [5†L16-L24].
5. Extendable product lifecycle — BlockCore™ effectively extends product lifecycle, making investment in the CTN‑W1592A more cost‑efficient over the long term, particularly for multi‑site camera‑enabled deployments spanning multiple years.
What protection does SafeCore™ provide for camera‑equipped industrial deployments?+
SafeCore™ is CESIPC’s system‑level power‑loss protection architecture built into the CTN‑W1592A. In industrial, kiosk, and remote monitoring environments, power interruptions are common — grid fluctuations, maintenance lockout/tagout, or voltage dips from nearby heavy equipment — events that can corrupt OS files and video logs if power is removed abruptly. SafeCore™ provides:
• System‑level write protection — Blocks all unauthorised changes to the system; even after power failure, user error, or malware attack, system files automatically restore after reboot. For security kiosks and access control stations, this prevents tampering and ensures rapid recovery.
• One‑reboot recovery mechanism — System crash or file corruption? Just reboot — the system returns to a healthy working state. No technical skills needed. On‑site personnel can restore service in minutes without waiting for IT support.
• Zero IT support required — Anyone on site (security guard, facility manager) can recover the system with a simple restart, reducing downtime and on‑call IT costs.
• Safe disk writes — Prevents fragmentation or file corruption during sudden power loss, ensuring data integrity for video logs, facial recognition records, equipment status images, and quality control data.
Combined with auto power‑on recovery (the system automatically restarts when power returns) and 9–36V DC wide‑range input (tolerates voltage fluctuations from industrial equipment), SafeCore™ ensures continuous operation even on electrically noisy factory floors. SafeCore™ is standard across all CTN‑W1592A models and works in tandem with TPM 2.0 hardware security for encrypted authentication and data protection [0†L13-L15].
What are the mechanical specifications, mounting options, and environmental ratings?+
Dimensions: 404.2(W) × 253.5(D) × 75.1(H) mm — fits standard 15.6‑inch panel cutouts. Weight: 6.1 kg net [0†L28-L30].
Cutout dimensions: 388.0 × 237.3 mm — standard industrial panel cutout for easy retrofit compatibility.
Mounting: Wall mount / VESA mount (100×100mm) — flexible installation on articulated arms, machine frames, or flush integration into control cabinets and kiosk enclosures. The 75.1mm depth leaves ample room for cabling behind the panel.
Enclosure: Industrial‑grade 6061 high‑strength aluminum alloy chassis — corrosion‑resistant and durable for 24/7 operation. Front panel IP65‑rated for dust and splash resistance, with the camera fully sealed behind the front panel [0†L13-L15][2†L10-L11].
Cooling: Fanless passive cooling — no moving parts, zero scheduled maintenance. Silent operation meets noise‑sensitive control room, kiosk, and office environment requirements.
Display: 15.6‑inch 16:9 TFT LCD, 1920×1080 Full HD resolution, 300 cd/m² brightness, 500:1 contrast ratio, 50,000 hours LED backlight life. Touch: 10‑point projected capacitive (standard) or optional resistive touch for gloved operation.
Operating temperature: 0°C ~ 50°C standard; optional -40°C ~ 70°C extended grade for cold storage, outdoor remote sites, and extreme environments [0†L26-L27].
Storage temperature: -10°C ~ 60°C.
Humidity: 10% ~ 90% RH, non‑condensing [0†L27].
Power input: 9~36V DC wide‑range input with standard 12V DC — directly accepts 24V industrial power rails without additional DC‑DC conversion. Boot modes: AT (auto power‑on) for unattended operation, or ATX (power button) for manual control [0†L11-L12].
Certifications: CE, FCC, BIS compliant (EN 55032 & EN 55035), factory ISO9001:2015 certified. MTBF 60,000 hours.
Key applications based on specification: Facial recognition access control, equipment status logging, remote assistance, smart retail security, intelligent transportation kiosks, industrial automation vision stations, and edge AI inference [0†L3-L7].
What are typical applications for the CTN‑W1592A camera panel PC?+
The CTN‑W1592A is a 15.6‑inch fanless industrial panel PC with a built‑in high‑definition front camera, designed for applications requiring integrated imaging, IP65 front protection, and scalable processing power in a compact footprint. Typical applications include:
• Facial recognition access control & operator authentication — Deployed at manufacturing facility entrances, cleanroom access points, and secure equipment workstations. The built‑in camera captures operator faces for biometric authentication, eliminating the need for RFID badges or separate USB cameras. The front panel’s IP65 rating withstands daily cleaning in hygienic environments. 6 USB ports connect to card readers, printers, and additional peripherals. For multi‑factor authentication deployments, CTN‑W1592A can be combined with RFID and fingerprint modules available in the RFID‑integrated panel PC series [9†L3-L4].
• Equipment status logging & visual inspection — Deployed on production lines for operators to capture images of equipment before/after maintenance, log visual defects, or document quality inspection results. The 8MP 4K UHD camera model (Cam‑AF4K) captures fine detail for defect documentation, while the 60 fps model (Cam‑QR720) supports high‑speed scanning. Dual M.2 NVMe storage logs images and inspection data locally, with 2×GbE LAN for upload to quality management systems.
• Remote assistance & guided maintenance — Deployed at remote equipment locations or field service sites. The built‑in camera allows field technicians to stream real‑time video to remote experts for troubleshooting, parts identification, and repair guidance. The built‑in microphone supports two‑way audio communication. 9–36V wide‑range input and optional -40°C ~ 70°C wide‑temperature support deployment in unheated or outdoor environments. The 12th Gen Core i7 platform with Iris Xe Graphics handles video encoding and real‑time streaming without dedicated capture hardware.
• Smart retail & self‑service kiosks — Deployed as customer‑facing kiosks for age verification, loyalty program enrolment, or automated checkout. The built‑in camera captures customer faces for age estimation or facial payment authentication. The 15.6‑inch Full HD display provides clear customer interaction while maintaining a compact footprint for kiosk integration. IP65 front panel protects against cleaning agents and spills. The optional IR night vision camera model (Cam‑IR720) supports 24/7 operation in dimly lit retail environments.
• Industrial automation & machine vision — Deployed as an operator station with integrated vision for defect detection, assembly verification, or barcode/QR code reading at the workstation. The 60 fps camera model (Cam‑QR720) is optimised for high‑speed barcode scanning. 3×RS232 ports interface with PLCs, torque tools, and sensors for closed‑loop verification. The 12th Gen Core i7 platform with dual M.2 NVMe storage processes images locally and uploads results to MES or SCADA systems via dual GbE LAN.
• Intelligent transportation & public information kiosks — Deployed at airport self‑service check‑in, border control kiosks, and public transportation ticketing stations. The built‑in camera captures passenger faces for biometric matching against travel documents. IP65 front panel protects against cleaning agents in public spaces. 4×USB 3.0 ports connect to passport scanners, boarding pass printers, and payment terminals. For public transportation applications requiring integrated RFID, see our 21.5‑inch RFID‑integrated panel PC series [9†L7-L11].
For detailed application examples, see our facial recognition access control guide and camera‑integrated panel PC overview.
Can CESIPC provide OEM/ODM customisation for the CTN‑W1592A?+
Yes. CESIPC offers full OEM/ODM services for the CTN‑W1592A camera panel PC series, built around the BlockCore™ modular architecture [0†L31]:
• BIOS configuration and boot logo branding — For private labeling, brand consistency, and OEM turnkey solutions.
• Camera model selection & tuning — Factory configuration of camera model (AF1080, FF720, AF4K, IR720, QR720) and firmware optimisation for specific lighting conditions, object distances, or scan rates. Autofocus calibration, low‑light sensitivity, and IR cut‑filter behaviour can be tuned per application requirements.
• I/O panel customisation — Alternative connector arrangements, additional COM ports, isolated digital I/O, or CAN bus via i‑Door expansion modules.
• Function board customisation — Custom i‑Function Board development for specific industrial protocols or proprietary interfaces. The LEGO MODE ecosystem enables rapid function board development, dramatically reducing customisation lead times.
• Operating system pre‑load — Windows 10/11 LTSC or Ubuntu Linux with custom drivers, pre‑configured camera settings, and pre‑installed runtime environments for vision applications.
• Enclosure material options — Enhanced corrosion resistance for marine, chemical, or outdoor roadside environments. Anti‑microbial coating options for healthcare and cleanroom applications.
• Private label packaging and custom SKU part numbering for integrators and reseller programs.
With in‑house SMT assembly, sheet metal fabrication, and CNC machining, CESIPC delivers custom industrial panel PCs with consistent quality and predictable lead times. MOQ: 1 unit sample available. Typical lead time: 2–4 weeks. Minimum order quantities vary by customisation scope. Contact our engineering team for a detailed ODM assessment.
