Product Features:
- Core Technology: Streaming media switching and transmission, audio and video encoding/decoding, mobile network communication, cloud computing services.
- Communication Technology: 4G/5G communication networks, private networks, MESH self-organizing networks, satellite communication.
- Operating System: Supports Windows 10 and Linux System.
- Protection Level: Full aluminum alloy body, achieving IP53 protection level.
- Triple-Screen Display: Three 15.6-inch LQ TFT LCD screens, each with a resolution of 1920 * 1080.
- Processor: Intel Core i7-10870H, 8 cores, 16 threads.
- Functional Features: On-site video conferencing, real-time audio and video transmission and sharing, cross-regional group intercom, linked alarms, image capture, GPS/BeiDou positioning, trajectory tracking and playback, electronic fence attendance, task dispatch, command issuance, and dynamic group scheduling.
Product Description:
The CTN-1580K Triple-Screen Rugged Portable Computer is an all-in-one portable command and dispatch platform with three integrated screens. It is built on core technologies such as streaming media switching and transmission, audio and video encoding/decoding, mobile network communication, and cloud computing services.
Leveraging existing 4G/5G communication networks, private networks, MESH self-organizing networks, and satellite communication, it offers a range of powerful features, including on-site video conferencing, real-time audio and video transmission and sharing, cross-regional group intercom, linked alarms, image capture, GPS/BeiDou positioning, trajectory tracking and playback, electronic fence attendance, task dispatch, command issuance, and dynamic group scheduling. This enables seamless integration between front-end devices and the command center, achieving intelligent and comprehensive command and dispatch operations.
Product Specifications:
| Category | Specification |
|---|---|
| Motherboard | Customized industrial motherboard by KELADE |
| Processor | Intel Core i7-10870H, 8 cores, 16 threads, base clock 2.2GHz, max turbo 5.0GHz |
| Memory | 32GB, expandable up to 128GB |
| Graphics Card | Configurable MXM independent graphics card |
| Display | 3 x 15.6-inch LQ TFT LCD (single screen resolution 1920*1080) |
| Storage | 512GB SSD NVMe + 1TB SSD SATA |
| Battery Life | Up to 4 hours at room temperature |
| Power Input | DC 19V |
| Keyboard | Industrial keyboard with touchpad |
| Brightness | Adjustable from 400 to 1000 cd/m² |
| Contrast Ratio | 500:1 |
| LAN | 2 x 10/100/1000Mbps RJ45 ports |
| USB Ports | 4 x USB 3.0 ports |
| Serial Port | 1 x RS-232 serial port |
| HDMI Outputs | 3 x HDMI outputs |
| Audio | 1 x 3.5mm audio input/output jack |
| Camera | Built-in 500W HD camera |
| Microphone | 1 x gooseneck microphone |
| Customization Options | Supports 4G full network communication, WiFi 802.11ac, middle screen with built-in 500W camera |
| Dimensions | Approx. 395 x 295 x 90.4mm (excluding protective corners) |
| Weight | 8.866kg |
| Operating Temperature | -10°C to 70°C |
| Storage Temperature | -20°C to 70°C |
| Relative Humidity | 10~95% @ 40°C (non-condensing) |
| Protection Level | IP53-rated enclosure |
| Operating System | Windows 10, Linux System |
Application Fields
The CTN-1580KB rugged portable three-screen terminal is widely used in various fields, including epidemic prevention, traffic and patrol police, emergency response, armed police, civil defense, border defense, urban management, safety supervision, firefighting, power grid maintenance, railway inspection, forest fire prevention, military operations, and other large-scale security activities. It enables real-time information collection and reporting, effective incident control, rescue resource deployment, and event handling, significantly improving emergency command efficiency.
