Rugged Tablet TPC-1082A
The TPC-1082A is a 10.1-inch fanless rugged tablet PC built for field operations and industrial deployment. Powered by Intel® 7th Gen Core i3/i5/i7 processors (up to 3.50GHz), it integrates 4G LTE, Wi-Fi 802.11ac, Bluetooth 4.0, and GPS with Beidou/GLONASS support in a single IP65-rated device — eliminating the need for external dongles or modules in field environments.
The tablet withstands 1.2-metre drops, 10g mechanical shock, and continuous vibration, with a high-strength plastic and TPU corner guard chassis weighing just 1.5kg. With a MTBF of ≥50,000 hours, dual cameras (2MP front / 5MP rear), and a 5,000mAh battery providing up to 4 hours of operation, it is designed for logistics inspection, field service, warehouse management, and mobile industrial HMI applications.
Product Features
- Intel 7th Generation Core Processor
- 10.1″ HD high-brightness, multi-touch, Gorilla Glass Panel
- Built-in 4G LTE, WLAN (802.11 a/b/g/n/ac), BT4.0, and GPS modules with Beidou/GLONASS support
- Low power consumption
- Fanless design and low power consumption
- Front Panel IP65 Level
- Supports Win 7/Win 10/ Linux OS
- Download Specification
Product Specifications
| CPU | Intel® i3-7100U Dual Core up to 2.40 GHz 3M Cache, TDP 15W Intel® i5-7200U Dual Core up to 3.10 GHz 3M Cache, TDP 15W Intel® i7-7500U Dual Core up to 3.50 GHz 4M Cache, TDP 15W |
| Cooling System | Fan cooling |
| Memory | 1x DDR4 2133Mhz SO-DIMM Sockets, up to 16GB |
| Storage | mSATA SSD |
| I/O ports | 2xUSB3.0(Type-A) |
| 2xRJ45 LAN | |
| BT 4.0/WIFI | |
| HDMI (3840*2160 @30Hz) | |
| Speaker | |
| Expansion | GPS/COMPASS/RS232 |
| Input Voltage | 19V DC (2 Pin Aviation Connector) |
| Display Type: | 10.1inch TFT LED Panel( LED Backlight) |
| Max. Resolution: | 1280×800 |
| Luminance(cd/㎡) | 400nits |
| Backlight Lifetime | 30,000hrs (typical) |
| Touch Type | Projected Capacitive Touch, 2-10 Touch Points |
| Touch Controller | USB |
| Durability(Touches) | 36 million |
| Battery | Li-ion Battery: 5000mAh, 4 Working Hours |
| OS Support | Microsoft Windows 7/ Windows 10/ Linux |
| Operating Temperature | 0℃～50℃(32~ 122 °F)(extend temperature optional) |
| Storage Temperature | -10℃～60℃(14 ~ 140 °F) (extend temperature optional) |
| Camera | Front 2M pixel / Back 5M pixel with flash |
| Anti-shock | 10g Acceleration, 11ms Duration |
| Anti-vibration | 5-19Hz/1.0mm Amplitude; 19-200Hz/1.0g Acceleration |
| Anti-fall | 1.2M |
| Reliability | MTBF≥50000h; MTTR≤0.5h |
| Operating Humidity | 95% @40℃ (104℉), non-condensing |
| Front Panel Protection | IP65 compliant |
| Dimensions | 278W)*198(D)*30(H)mm |
| Weight | 1.5kg(3.31lb) (NW/GW) |
| Color | Black |
| Material | High Strength Plastic, TPU Corner Guard |
FAQ
Q: What is the TPC-1082A used for?
A: The TPC-1082A is a 10.1-inch rugged tablet PC designed for field service, logistics inspection, warehouse management, mobile industrial HMI, and outdoor data collection. Its built-in 4G LTE, GPS, Wi-Fi, and Bluetooth modules make it self-contained for field deployments where external connectivity hardware is impractical. The IP65 front panel and 1.2-metre drop resistance make it suitable for use on factory floors, construction sites, and outdoor inspection environments.
Q: Does the TPC-1082A have built-in 4G and GPS?
A: Yes. The TPC-1082A includes built-in 4G LTE (full network compatibility), GPS with Beidou and GLONASS support, Wi-Fi 802.11 a/b/g/n/ac, and Bluetooth 4.0 — all integrated into the device. No external dongles or modules are required. This makes it ready for immediate field deployment with real-time connectivity and location tracking.
Q: How durable is the TPC-1082A?
A: The TPC-1082A is rated for 1.2-metre drop resistance, 10g mechanical shock (11ms), and continuous vibration up to 200Hz. The front panel meets IP65 protection (dust-tight and water-jet resistant). The chassis uses high-strength plastic with TPU corner guards. Reliability is rated at MTBF ≥ 50,000 hours and MTTR ≤ 0.5 hours — making it suitable for 24/7 field operations.
Q: How long does the battery last on the TPC-1082A?
A: The TPC-1082A is equipped with a 5,000mAh lithium-ion battery providing approximately 4 hours of continuous operation. For extended field shifts, CESIPC can advise on power management configurations or hot-swap battery options — contact the sales team for details.
Q: What operating systems does the TPC-1082A support?
A: The TPC-1082A supports Windows 7, Windows 10, and Linux. Windows 10 is the recommended OS for most industrial and field service applications. Custom OS configurations and BIOS settings are available through CESIPC’s OEM/ODM service.
Q: What is the operating temperature range of the TPC-1082A?
A: The standard configuration operates from 0°C to 50°C. An extended temperature option is available for environments outside this range. Storage temperature is rated at -10°C to 60°C. The device also operates up to 95% relative humidity at 40°C (non-condensing).
